Product Model: SDS198
-
Measuring Parameters: PM2.5 & PM10
-
Measuring Principle: Laser scattering
-
Particle Size Detection: ≥ 0.3 μm
-
Measurement Range:
-
PM2.5: 0 – 1000 µg/m³
-
PM10: 0 – 1000 µg/m³
-
-
Response Time: ≤ 10 seconds
-
Accuracy: ±10 µg/m³ (0–100 µg/m³), ±10% (100–1000 µg/m³)
-
Output Method: UART (digital output)
-
Operating Voltage: 5.0 V ± 0.1 V
-
Operating Current: ≤ 100 mA
-
Standby Current: ≤ 2 mA
-
Operating Temperature: -20°C ~ +50°C
-
Operating Humidity: 0 – 70% RH (non-condensing)
-
Storage Temperature: -40°C ~ +80°C
-
Service Life: Up to 8000 hours continuous operation
-
Dimensions: 75 × 67 × 23 mm
Dust sensor
Nova pm2.5 PM10 SDS198 Sensor
₹6,500.00 Price With Tax
-
High-precision laser-based PM2.5 & PM10 sensor
-
Real-time detection with fast response time (≤10s)
-
Built-in fan ensures stable airflow and measurement
-
Digital UART output for easy integration with IoT systems
-
Wide measuring range: 0–1000 µg/m³
-
Compact, low power, and long service life (~8000 hrs)
-
Ideal for air purifiers, HVAC, smart homes, and monitoring stations
Availability: 47 in stock
15 Days Warranty
This product comes with a 15-day warranty starting from the date of delivery. The warranty covers manufacturing defects only. If a defect is confirmed, the item will be replaced.
Warranty will not apply if:
-
The product has been misused, dropped, or damaged.
-
It has been exposed to water, fire, chemicals, or static discharge.
-
It has been tampered with, soldered, or altered in any way.
The Nova PM SDS198 is a high-precision laser dust sensor designed to measure PM2.5 and PM10 concentrations in the air. Using advanced laser scattering technology, it detects fine particles with exceptional accuracy and outputs real-time data via a digital interface.
The SDS198 is compact, reliable, and energy-efficient, making it ideal for integration into air purifiers, HVAC systems, environmental monitoring equipment, smart home devices, and air quality monitoring stations.
It comes with a built-in fan for stable airflow, ensuring continuous and accurate particle measurement over long durations. With its UART digital output, the SDS198 can be easily integrated into embedded systems and IoT applications.
Package Includes:
-
1 Cable & SDS198 Sensor
| Weight | 0.200 kg |
|---|---|
| Dimensions | 7.5 × 6.7 × 2.3 cm |
